Canon camera parts quiz: Identify key components

Quick, free way to identify camera parts. Instant results.

Editorial: Review CompletedCreated By: Insyirah JamaludinUpdated Aug 23, 2025
Difficulty: Moderate
2-5mins
Learning OutcomesCheat Sheet
Paper art illustration of Canon camera lens, viewfinder, shutter button, battery grip on golden yellow background

This quick Canon camera parts quiz helps you spot and name key components - buttons, dials, ports, and mounts - so you can shoot with confidence. Brush up broader skills with our photography knowledge quiz, pick your next body with the best camera for me quiz, or refine composition in the camera angle quiz.

What part of the Canon camera holds the lens?
Mount adapter
Lens mount
Bayonet ring
Lens release button
The lens mount is the interface on a Canon camera body where lenses are securely attached. It includes alignment marks and electronic contacts that communicate between the camera and lens. The lens release button disengages the mount for removal but does not hold the lens in place. .
What is the name of the camera's light-sensitive unit?
Viewfinder
Flash unit
Image sensor
Mirror
The image sensor, commonly a CMOS sensor in Canon cameras, converts incoming light into electrical signals. It is the core component responsible for capturing the photograph. Other parts like the viewfinder or mirror aid in composition but do not record light. .
Which button do you press halfway to activate autofocus on a Canon DSLR?
Movie record button
Drive mode dial
Power switch
Shutter button
On Canon DSLRs, pressing the shutter button halfway activates the autofocus system and exposure metering. This is the standard behavior unless customized in custom functions. The movie record button only starts or stops video recording. .
What is the flip-out screen on the back of many Canon cameras called?
Articulating LCD
Viewfinder
Touch pad
Top LCD panel
An articulating LCD is a screen that can tilt and swivel to aid in shooting from various angles. This is common on many Canon models for video and low-high angle shooting. The viewfinder is where you look through to compose, and the top panel displays basic settings. .
What is the small window you look through to compose shots on a DSLR?
Viewfinder
Live View screen
Status LCD
Optical sensor
The viewfinder on a DSLR lets you compose images through the lens via a mirror and prism system. Live View uses the rear screen and not an optical path. The status LCD is usually a small top display showing settings. .
Which memory card type is most commonly used in modern Canon DSLR cameras?
SD card
Memory Stick
microSD
CompactFlash
Most current Canon DSLRs use SD cards (including SDHC and SDXC) for storage. Older professional bodies sometimes supported CompactFlash, but SD is now the industry standard. Memory Stick is proprietary to Sony, and microSD is too small for full-size card slots. .
What mount on top of the camera holds external flashes or accessories?
Hot shoe
Accessory port
Cold shoe
Accessory lug
The hot shoe provides both a mechanical mount and electrical contacts for flash units and other accessories. A cold shoe lacks electrical contacts. Accessory ports are typically proprietary, and lugs are for straps. .
Which battery model is used in many Canon EOS DSLR cameras?
CR2
NP-FW50
EN-EL15
LP-E6
The LP-E6 battery is common in many Canon EOS DSLR models, including the 5D and 7D series. EN-EL15 is used by Nikon, and NP-FW50 by Sony mirrorless. CR2 is a lithium cell used in smaller devices. .
Which button do you press to start video recording on most Canon DSLRs?
Movie record button
Info button
Live View switch
Menu button
The dedicated movie record button on Canon DSLRs starts and stops video recording once Live View is engaged. The Live View switch enables the sensor feed to the LCD but doesn't start recording. Menu and Info buttons navigate settings and overlays. .
Which ring on a zoom lens do you turn to change the focal length?
Control ring
Zoom ring
Focus ring
Aperture ring
The zoom ring on a zoom lens adjusts the focal length to zoom in or out. The focus ring adjusts focus distance, and the aperture ring (on some lenses) sets the iris. The control ring may be custom-mapped but isn't for zoom. .
Which dial on a Canon DSLR is commonly used to quickly adjust shutter speed or exposure settings?
Drive mode dial
Power switch
Mode dial
Main dial
The main dial, located near the shutter button, is used to adjust exposure parameters like shutter speed in manual or shutter-priority modes. The mode dial selects shooting modes, and the drive mode dial changes burst or single shot. The power switch turns the camera on or off. .
Which port on a Canon camera is used for USB connection to a computer?
USB port
HDMI port
Headphone port
Microphone port
Canon cameras have a USB port (often Mini or Micro USB) for tethered shooting and file transfer. HDMI ports send video and audio signals to external monitors. Microphone and headphone ports handle audio input and monitoring. .
What screw-type socket at the bottom of the camera is used to attach a tripod?
Tripod socket
Memory card slot
Battery compartment
Strap lug
The tripod socket is a threaded metal hole on the camera base that fits standard tripod screws (1/4"-20 UNC). The battery compartment and memory card slot open to insert power or storage, and strap lugs hold carrying straps. .
Which button on a Canon DSLR is used to change ISO sensitivity?
AF button
WB button
Metering button
ISO button
Pressing the ISO button on a Canon DSLR and turning the main dial adjusts the camera's ISO sensitivity. WB adjusts white balance, AF controls autofocus settings, and metering buttons change metering modes. .
Which switch or lever engages Live View mode on most Canon DSLRs?
Drive mode button
Mode dial
Power switch
Live View switch
The Live View switch or lever raises the mirror and provides a live sensor feed to the rear LCD. The mode dial picks shooting modes, the power switch turns the camera on/off, and drive mode changes shooting speed. .
What is the name of Canon's proprietary image processor found in its cameras?
Venus Engine
DIGIC
Expeed
BIONZ
DIGIC is Canon's in-house image processor that handles tasks like noise reduction, color processing, and autofocus algorithms. BIONZ is used by Sony, Expeed by Nikon, and Venus Engine by Panasonic. The version number (e.g., DIGIC 8) indicates processor generation. .
Which lens line is specifically designed for APS-C Canon DSLR cameras?
EF
RF
FD
EF-S
EF-S lenses are optimized for APS-C sensor bodies in Canon DSLR cameras and have a shorter back focus distance. EF lenses cover full-frame sensors, RF lenses fit mirrorless RF mounts, and FD is an older manual-focus mount. .
What mount does Canon use on its full-frame mirrorless cameras?
RF mount
EF-M mount
FD mount
EF mount
Canon's RF mount is designed for its full-frame mirrorless EOS R series, providing a shorter flange focal distance and support for new optical designs. EF mount is for DSLRs, EF-M for APS-C mirrorless, and FD is a legacy mount. .
Which assembly houses the reflex mirror and the shutter mechanism in a Canon DSLR?
Shutter housing
Sensor chamber
Viewfinder prism
Mirror box assembly
The mirror box assembly contains both the reflex mirror and the shutter curtains in a DSLR. It sits between the lens mount and the image sensor. The viewfinder prism directs light to your eye but does not house the shutter. .
What transmits lens metadata and control signals between Canon lenses and camera bodies?
Bayonet tabs
Optical fibers
Mechanical levers
Electronic contacts
Electronic contacts on the lens mount relay autofocus, aperture, image stabilization, and EXIF data between lens and body. Mechanical levers were used for aperture in older lenses but carry no data. Bayonet tabs secure the lens mechanically. .
What is the purpose of the depth-of-field preview button on a Canon DSLR?
Activates live histogram
Zooms viewfinder image
Locks autofocus
Stops down the lens to preview depth of field
Pressing the depth-of-field preview button stops the lens to the selected aperture, allowing you to see the actual depth of field through the viewfinder. It does not activate histograms or zoom. This helps in critical depth-of-field compositions. .
Which dial on a Canon DSLR is primarily used to navigate menus and change settings?
Main Dial
Exposure Compensation Dial
Mode Dial
Quick Control Dial
The Quick Control Dial on Canon DSLRs lets you scroll through menus, adjust ISO, aperture, and navigate images. The main dial adjusts settings near the shutter button, while the mode dial changes shooting modes. Exposure compensation has its own control. .
Which component in a Canon DSLR is dedicated to phase-detection autofocus?
AF sensor
Metering sensor
Image processor
CMOS sensor
A separate AF sensor in Canon DSLRs receives light redirected by the reflex mirror to perform fast phase-detection autofocus. The CMOS sensor handles imaging, the metering sensor calculates exposure, and the image processor handles data processing. .
Which port on a Canon camera is used for input from an external microphone?
Flash sync terminal
USB port
Headphone port
3.5mm mic port
The 3.5mm microphone port on Canon cameras accepts external audio input, allowing higher-quality sound than the built-in mic. The headphone port is for monitoring, flash sync is for strobes, and USB is for data transfer. .
What does IS stand for on Canon lenses?
Infrared Sensor
Internal Shutter
Image Sensor
Image Stabilization
IS stands for Image Stabilization, a system in Canon lenses that compensates for camera shake by moving lens elements. It is not related to infrared sensors or shutters. This helps in low-light and telephoto shooting. .
What does the dioptric adjustment knob allow you to change?
LCD backlight brightness
Viewfinder focus
Aperture size
Lens focal length
The dioptric adjustment knob fine-tunes the viewfinder's focus to match your eyesight. It does not affect the lens optics, LCD brightness, or aperture. Proper adjustment ensures a crisp viewfinder image. .
Which ring on some Canon lenses allows direct manual aperture control?
Control ring
Focus ring
Aperture ring
Zoom ring
The aperture ring on certain Canon lenses (especially older or cine-style) manually sets the lens diaphragm. The control ring can be custom-mapped, while zoom and focus rings adjust focal length and focus distance respectively. .
Which button on Canon cameras toggles the on-screen information display?
Q button
Menu button
Info button
Playback button
The Info button cycles through data overlays and display modes on the camera's LCD and top panel. The Menu button opens the full menu, Q brings up quick settings, and Playback shows captured images. .
Which feature on Canon DSLRs helps protect against dust and moisture ingress?
Hot shoe gasket
Lens hood
Rubber eyecup
Weather sealing
Weather sealing uses gaskets and seals at body seams, buttons, and lens mounts to keep dust and moisture out. A hot shoe gasket alone is insufficient, rubber eyecups block light ingress, and lens hoods shield from flare. .
Which indicator on a Canon camera displays remaining battery charge?
Memory card symbol
Battery level indicator
AF point display
Exposure meter
The battery level indicator shows how much charge remains, typically in bars or a percentage on the LCD or viewfinder. Memory card icons show card status, exposure meters show metering info, and AF point displays show focus points. .
What does the "X-Sync speed" setting on a Canon camera refer to?
Flash recycle time
Maximum sync speed for continuous shooting
Maximum ISO for flash mode
Maximum shutter speed for flash synchronization
X-Sync speed is the fastest shutter speed at which the camera's curtains are fully open to allow a flash burst to illuminate the entire sensor evenly. Exceeding this speed causes shading. It is not an ISO or recycle setting. .
How many electrical contacts are present on the Canon EF lens mount?
12
5
8
16
The Canon EF mount features 8 electronic contacts that transmit data such as autofocus commands, aperture information, and lens-specific data. Third-party and legacy mounts often have different counts. This design supports EF and EF-S lenses alike. .
What is the flange focal distance of the Canon EF mount?
52 mm
42 mm
44 mm
50 mm
The flange focal distance for Canon's EF mount is 44 mm, which is the distance from the lens mount flange to the sensor plane. This dimension allows adapters for other systems and influences lens design. Smaller distances are used in mirrorless mounts. .
What optical component in a DSLR corrects and inverts the viewfinder image?
Beamsplitter
Concave mirror
Fresnel lens
Pentaprism
A pentaprism in a DSLR viewfinder bends and flips the light from the reflex mirror, producing an upright and correctly oriented image. Fresnel lenses can aid in light distribution but don't invert. Concave mirrors and beamsplitters serve other optical functions. .
Which shutter type can be used in Canon mirrorless cameras to minimize rolling shutter artifacts?
Leaf shutter
Global mechanical shutter
Focal-plane shutter
Electronic shutter
Electronic shutters read the entire sensor simultaneously, reducing rolling shutter in fast-moving subjects. Focal-plane shutters expose line by line, which can introduce distortion. Leaf shutters reside in lenses, and global mechanical shutters are rare. .
What technology allows every pixel on some Canon sensors to perform phase-detection autofocus?
Hybrid AF II
Dual Pixel CMOS AF
Contrast AF
Phase detect mirror
Dual Pixel CMOS AF splits each pixel into two photodiodes for phase-detection, enabling fast and accurate autofocus across most of the frame. Contrast AF relies solely on sensor readouts and is slower. Hybrid AF II is Panasonic's system. Mirror-based PD AF is used in DSLRs. .
What is the function of the PC Sync terminal on some Canon cameras?
Remote shutter release
HDMI output
Audio input
External flash synchronization
The PC Sync terminal sends a trigger signal to off-camera flash units via a cable for precise sync. Remote releases and audio inputs use different ports, and HDMI is for video output. The PC (Prontor-Compur) standard has been around for decades. .
What is the purpose of the camera's buffer memory?
Holding firmware updates
Caching live view feed only
Temporarily storing images before writing to the card
Storing video files permanently
The buffer memory holds image data in high-speed RAM after capture, allowing continuous shooting before the data is written to a slower memory card. It is not used for firmware or permanent storage. Live View buffering is separate. .
Which component converts analog signals from the sensor into digital data in a Canon camera?
Optical low-pass filter
Shutter actuator
DSP chip
A/D converter
An analog-to-digital (A/D) converter transforms the analog voltage from each sensor pixel into digital values. The DSP (digital signal processor) further processes these values. Optical low-pass filters and shutter actuators serve other functions. .
What is the role of the focusing screen in a DSLR?
Acts as a touch-sensitive interface
Provides a projection surface for the viewfinder image
Houses the autofocus motor
Protects the sensor from dust
The focusing screen sits between the mirror and eyepiece, giving a translucent surface onto which the lens projects the image for manual focusing. It doesn't protect the sensor, nor is it touch-sensitive or related to autofocus motors. .
Which port on a Canon camera is used to output high-definition video and audio?
HDMI port
PC Sync terminal
Mic port
USB port
The HDMI port on Canon cameras sends uncompressed HD video and audio to external monitors or recorders. USB is for data transfer, PC Sync for flash, and the mic port for audio input only. .
What does the Mirror Lock-Up function do in Canon DSLRs?
Secures the battery compartment
Locks the lens aperture open
Prevents mirror movement before exposure to reduce vibration
Locks autofocus for long exposure
Mirror Lock-Up flips the reflex mirror up prior to exposure to minimize camera shake caused by mirror slap, useful in macro or long exposures. It does not affect the aperture, autofocus lock, or battery compartment. .
How does a Canon camera differentiate EF-S lenses from EF lenses to prevent damage?
A physical mount stop and electronic detection
Color-coded rear element
Unique bayonet shape
Different flange focal distance
EF-S lenses have a physical plastic stop that prevents mounting on full-frame bodies, and the camera body detects lens type via electronic contacts to disable incompatible modes. They share the same bayonet shape and flange distance. .
Which sensor in Canon DSLRs measures scene brightness for automatic exposure?
Ambient light sensor
Metering sensor
CMOS sensor
AF sensor
The metering sensor evaluates light intensity across multiple zones to calculate exposure settings automatically. The AF sensor measures focus, the CMOS sensor captures the image, and ambient light sensors adjust LCD brightness. .
What is an electronic front-curtain shutter in Canon mirrorless cameras?
Is purely software-based noise reduction
Starts exposure electronically and ends with mechanical rear curtain
Uses no mechanical parts at all
Refers to the front LCD screen shutter
An electronic front-curtain shutter begins the exposure electronically, eliminating the first mechanical curtain movement to reduce vibration. The mechanical rear curtain still closes to end the exposure. It's not a fully electronic or software-only feature. .
Which communication protocol is used over the Canon EF mount contacts to transmit lens information?
USB
UART
SPI
I2C (SMBus)
Canon EF mount lenses communicate via an I2C-based serial protocol (SMBus), enabling bidirectional data transfer for focus, aperture, and stabilization controls. SPI and UART are used in other fields but not on EF mounts. The mount does not utilize USB signals. .
How many autofocus areas are available with Dual Pixel CMOS AF in Canon EOS R series cameras?
819
45
1435
5655
Canon's EOS R series implements Dual Pixel CMOS AF across 5,655 manually selectable AF points, covering almost the entire frame. Traditional DSLRs had far fewer phase-detect points. This high count enables precise focus tracking. .
Which type of lens element in Canon L-series lenses is designed to reduce chromatic aberration?
Ultra-low Dispersion (UD) element
Aspherical element
Achromatic doublet
Fluorite element
UD elements are specialized glass elements used in Canon L-series lenses to minimize chromatic aberration by dispersing different light wavelengths more uniformly. Aspherical elements correct spherical aberrations, and fluorite elements are used in some telephoto lenses. Achromatic doublets are common in microscope optics. .
What mechanism allows silent shooting via electronic shutter in Canon mirrorless cameras?
Global electronic shutter
Rolling mechanical shutter
Mechanical front and rear curtains
Leaf shutter in lens
A global electronic shutter reads the entire sensor simultaneously without any mechanical curtains, enabling truly silent shooting. Leaf shutters are located in some lenses but not standard EOS R glass. Mechanical fronts and rolling shutters involve curtain movements or line-by-line reads, which are not fully silent. .
0
{"name":"What part of the Canon camera holds the lens?", "url":"https://www.quiz-maker.com/QPREVIEW","txt":"What part of the Canon camera holds the lens?, What is the name of the camera's light-sensitive unit?, Which button do you press halfway to activate autofocus on a Canon DSLR?","img":"https://www.quiz-maker.com/3012/images/ogquiz.png"}

Study Outcomes

  1. Identify Canon camera components -

    Learn to recognize essential canon camera components such as the lens mount, viewfinder, and image sensor to build a solid foundation in camera anatomy.

  2. Name key Canon camera parts -

    Master the official names of each part in our canon camera parts quiz, ensuring you can accurately refer to components in conversations or technical documents.

  3. Analyze component functions -

    Understand how each part works and contributes to image capture, enabling you to evaluate the role of every element in your photography gear.

  4. Apply component knowledge -

    Use your understanding of camera parts identification quiz concepts to make informed decisions about equipment setup and upgrades.

  5. Assess your proficiency -

    Gauge your strengths and areas for improvement in identifying canon camera components with immediate feedback from the quiz.

  6. Interpret component troubleshooting -

    Leverage your newfound knowledge to diagnose common issues and follow maintenance guidelines for optimal camera performance.

Cheat Sheet

  1. Image Sensor Basics -

    Canon's CMOS sensors convert light into electrical signals, and understanding pixel pitch and resolution (e.g., 24MP = 6000×4000 pixels) helps you ace any camera parts identification quiz. Remember that APS-C sensors have a 1.6× crop factor, so full-frame lenses yield tighter framing - use the mnemonic "Full Frame Feels Wider" to recall this. Official Canon whitepapers and IEEE publications confirm how sensor size impacts depth of field and noise performance.

  2. Lens Mount Types -

    Canon's EF, EF-S, and RF mounts each feature unique flange distances and electronic contacts; EF-S is APS-C only, while RF supports full-frame mirrorless bodies with faster communication. A handy tip is "S = Small Sensor," so if you see "S," it pairs with APS-C. This component detail is pulled from Canon's technical manuals and mount-system studies at major photography institutes.

  3. Shutter Mechanism -

    Most Canon DSLRs use a focal-plane shutter with dual curtains, offering speeds from 30s to 1/8000s and sync up to 1/200s. Knowing how curtain travel affects flash timing will help you identify camera parts accurately in a practical exam. Canon service guides and optical engineering journals outline how shutter curtain dynamics influence exposure consistency.

  4. Autofocus System -

    Modern Canon bodies employ Dual Pixel CMOS AF or phase-detection modules with dozens of cross-type points, boosting accuracy in both photo and video modes. Remember "Dual Pixels, Dual Precision" to quickly recall the hybrid AF approach in mirrorless models. Detailed sensor-AF interaction diagrams from Canon's developer documentation and university optics courses make this fact crystal clear.

  5. Viewfinder & LCD Interface -

    Canon's optical viewfinders (OVF) on DSLRs use pentaprisms for bright, lag-free framing, while EOS R-series electronic viewfinders (EVF) display real-time exposure preview at high resolution. When taking the camera parts identification quiz, note that "O" in OVF means "Optical," while EVF starts with "E" for "Electronic feed." Official Canon tutorials and imaging science textbooks highlight the pros and cons of each system.

Make a Quiz (FREE) Copy & Edit This Quiz Create a Quiz with AI

Electronics & Gadgets Quizzes

Powered by: Quiz Maker
